SENFENG SFCK8463 is a heavy CNC roll lathe for turning large rolls and shafts up to Ø630 mm and 3000 mm long, used to prepare and finish parts before and after laser cladding. A flat cast-iron bed, 3700 N·m spindle and four-station electric turret handle very heavy work.
Supplied on quotation. Choose the model above and tell us the part sizes and weights you turn in the quote form. We reply with the machine price, freight to your door (UK or worldwide) and lead time.
| Model | SFCK8463 |
|---|---|
| Max. part Ø (mm) | 630 |
| Max. part length (mm) | 3000 |
| Distance between centres (mm) | 3300 |
| Spindle taper | Metric 140 (1:20) |
| Front bearing Ø (mm) | 200 |
| Max. spindle torque (N·m) | 3700 |
| Rapid X / Z (m/min) | 10 / 7 |
| Stroke X / Z (mm) | 425 / 3000 |
| Footprint L×W (mm) | 7430×2489 |
| Power supply | 3-phase 380 V, 50/60 Hz |
Data from SENFENG; please confirm the final specification on your quotation.
SENFENG machines are made by Jinan Senfeng Laser Technology Co., Ltd., China, and supplied in the UK by LATHELAND.
