Lyndon Slot Drills Standard Series – Inch: Lyndon standard series 2-flute centre-cutting slot drills for slotting, pocketing and plunging, with a threaded shank. Inch sizes 1/16" to 1".
Introductory offer: 50% off the RRP until 30 November 2026. The RRP is shown crossed out next to the offer price. All prices exclude VAT.
| Diameter | Shank Ø | Length of cut | Overall length | Code HSS | Code HSS-Co M42 |
|---|---|---|---|---|---|
| 1/16" | 1/4" | 3/32" | 1-29/32" | SD/300 | SDC/300 |
| 1/8" | 1/4" | 9/32" | 2" | SD/310 | SDC/310 |
| 3/16" | 1/4" | 3/8" | 2-1/16" | SD/320 | SDC/320 |
| 1/4" | 1/4" | 7/16" | 2-7/32" | SD/330 | SDC/330 |
| 5/16" | 3/8" | 1/2" | 2-11/32" | SD/340 | SDC/340 |
| 3/8" | 3/8" | 9/16" | 2-3/8" | SD/350 | SDC/350 |
| 1/2" | 1/2" | 3/4" | 2-5/8" | SD/360 | SDC/360 |
| 5/8" | 5/8" | 7/8" | 2-27/32" | SD/370 | SDC/370 |
| 3/4" | 5/8" | 1" | 3-1/32" | SD/380 | SDC/380 |
| 1" | 1" | 1-1/16" | 3-3/4" | SD/390 | SDC/390 |
