Dobot Magician E6 Robot (includes ES01 Suction Cup)

In stock
SKU: 1100000203
£5,699.00 GBP

Questions about this product, a larger quantity or a shipping quote? Contact us.

The DOBOT Magician E6 is a desktop-grade six-axis collaborative robot for education and research. It accurately simulates real industrial automation, giving students hands-on experience with the same DobotStudio Pro software used on DOBOT's industrial cobots. Supplied with the ES01 electric suction cup.

Key features

  • Collision detection and a status light ring for safe classroom use
  • Built-in control box – plug-and-play desktop set-up
  • No-code drag-to-teach, graphical (Blockly) and Lua programming
  • Rich I/O and TCP/IP interfaces for secondary development, with curriculum materials available

What's included

  • Magician E6 robot arm
  • ES01 electric suction cup

Specifications

Axes 6
Payload 0.75 kg
Reach 450 mm
Repeatability ±0.1 mm
Max TCP speed 0.5 m/s
Max joint speed 120°/s
Weight ≤7.5 kg
Power 100–240 V AC, 50/60 Hz; 48 V 5 A DC
Power consumption 130 W
Communication 2 x Ethernet (TCP/IP, Modbus TCP); USB (wireless module)
IP rating IP20
Base size 162 x 120 x 103 mm
Mounting Desktop or 90° angle
Software DobotStudio Pro

Supplied by LATHELAND, DOBOT's UK partner. Contact us for application advice, integration support, lead times and education or multi-unit pricing.
