MAB 815

AFFORDABLE DRILLING & TAPPING MACHINE

Great power for a small price! The compact MAB 465 magnetic drilling tapping machine from the ProfiSTART series with electronic control and clockwise/ anticlockwise rotation.

A compact yet powerful model with an output of 1,150 W reversible motor ideal for drilling and tapping. Versatility for use in workshop and on the go with a transport weight of just 13 kg. For core drilling and thread cutting. With this new concept of machine BDS introduces a drilling as well as tapping machine an affordable low cost price range. The MAB 465 magnetic drilling tapping machine is equipped with grease gearbox, two speed, reversible motor which makes the machines economical for drilling and tapping operation. Made in Germany.

• Core Drilling 40/50 mm
• Cutting Depth 16 mm
•  Full wave control electronics

• Variable speed control
• Reversible motor
• Internal cabling
• Overheating protection
• Magnet indicator
• Two speed gearbox
• Grease gearbox

Technical specifications

Motor output	Watt	1150
Voltage, V AC	Volt	230 - 110/125
Core drill cutting depth max.	mm	55
Core drill max. Ø HSS/TCT	mm	40/50
Twist drill	≤ Ø mm	16
Reaming		---
Countersinking	≤ Ø mm	40
Thread cutting	≤ Ø mm	16
Stroke	mm	160
Magnet dimensions	mm	84 x 168 x 48
Weight	kg	13
Spindle taper		---
Arbor		Direct arbor 19 mm Weldon 3/4”
KEYLESS 19 mm Weldon 3/4“		---
Speed gears		2
Gear 1 range	min-1	50 – 250
Gear 2 range	min-1	100 - 450
Permanent internal lubrication		Yes
Safety clutch		---
Torque control		---
Full-wave control electronics		Yes
Magnetic Indicator		Yes
Overheating protection		Yes
Carbon brush wear control		---

Scope of delivery

1 Hexagonal offset screwdriver size 4

1 Ejector pin ZAK 075, 100

1 Hard-top case

1 Operating instructions

1 Safety lashing strap
